Frame
M5 hydroformed tubing, tapered HT, PF30 BB, ISCG ’05, Command Post routing, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 140mm travel
-
Headset
1-1/8 and 1-1/2" Threadless, Campy style upper with 1-1/2" lower, cartridge bearings
-
Seat binder
34.9mm clamp ID, 7050 hard anodized alloy collar w/ QR, black
-
Rims
Roval 26, alloy disk, 26mm wide, 32h
-
Front hub
Specialized Hi Lo disk, laser-etched logo, OS 24 end caps, sealed cartridge bearing, RWS, 32h
-
Rear hub
Specialized Hi Lo 142+ disk, laser-etched logo, double-sealed cartridge bearing, 12mm thru-axle, 32h
-
Spokes
DT Swiss Industry stainless 2.0 (14g)
-
Front tire
Specialized Purgatory Control, 120 TPI, 2Bliss ready, aramid bead, dual-compound, 26x2.2"
-
Rear tire
Specialized Ground Control, 60 TPI, 2Bliss ready aramid bead, 26x2.1"
-
Inner tubes
Ultralight presta valve
-
Rear shock
Custom Fox Triad II with AUTOSAG, custom on-the-fly 3-position compression switch 1) Lock out 2) Open 3) ProPedal, rebound adj., 197x51mm
-
Fork
Fox Evolution F140 RL, air spring, tapered steerer, LO and reb adj., standard drop-outs, 140mm
-
Front derailleur
SRAM X7, 10-speed, S3 direct mount for DMD, bottom-pull
-
Rear derailleur
SRAM X9, 10-speed, mid cage
-
Shift levers
SRAM X7, 10-speed, aluminum trigger
-
Cassette
SRAM PG-1030, 10-speed, 11-36t
-
Chain
KMC X-10, 10-speed, w/ reusable Missing Link, nickel plates
-
Crankset
Custom SRAM S-1250, 7050 alloy arms, 10-speed XC Trail double, PF30 spindle, S: 170mm, Others: 175mm
-
Chainrings
38/24, w/ alloy guard
-
Bottom bracket
SRAM PF30, OS press-in bearing, sealed cartridge
-
Seatpost
2014 butted alloy, single bolt setback, 30.9mm, S/M: 350mm, Others: 400mm
-
Stem
Specialized XC, 3D forged alloy, 4-bolt, 31.8mm clamp, adjustable rise, S: 60mm, M: 75, L:90, XL:105mm
-
Handlebars
Specialized All-Mountain low-rise, 6061 butted alloy, 720mm wide, 8º backsweep, 6º upsweep, 31.8mm
-
Grips
Specialized lock-on, S/M: Grappler, Others: Grappler XL
-
Saddle
Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm width
-
Front brake
Custom Avid Elixir 7 SL, hydraulic disk, alloy backed semi-metallic pad, HS-1 rotor S/M:180mm, Others: 200mm
-
Rear brake
Custom Avid Elixir 7 SL, hydraulic disk, alloy backed semi-metallic pad, HS-1 rotor S/M:160mm, Others: 180mm
-
Brake levers
Custom Avid Elixir 7 SL hydraulic, tool-less reach adj.
-
Pedals
Resin Test Ride Pedals with toe clips, CEN std.
