Frame
M5 alloy chassis and rear-end, Trail Geometry, SWAT Door integration, head tube angle adjustment, threaded BB, internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
Seat Binder
Alloy, 38.6mm
SWAT
SWAT 4.0 internal downtube storage
Fork
SRAM Rockshox Lyrik Ultimate, 29" 160mm
Rear Shock
Rockshox Super Deluxe Select GENIE, GENIE adjustable airspring, rebound adjust, 210x55mm
Front Brake
SRAM Maven Ultimate B1, 4-piston caliper, hydraulic disk, 200mm rotor
Rear Brake
SRAM Maven Ultimate B1, 4-piston caliper, hydraulic disk, 200mm rotor
Shift Levers
SRAM 90 trigger, 12-speed, single click
Rear Derailleur
SRAM Eagle 90 T-Type
Cassette
SRAM 12-speed, 10-52t
Chain
SRAM GX Eagle Transmission 12-Speed Flattop Chain
Crankset
SRAM Eagle 90, 55mm chainline, 32T
Bottom Bracket
SRAM DUB Threaded Wide
Front Tire
Butcher, GRID TRAIL casing, Gripton T9 compound, TLR, 29x2.4
Front Wheel
Roval Traverse Rim 29", hookless alloy, 30mm inner width, tubeless ready, DT Swiss 370 Hub, 15x110mm, 28h, Sapim Force Spokes
Rear Tire
Eliminator, GRID TRAIL casing, Gripton T7 compound, TLR
Rear Wheel
Roval Traverse Rim, hookless alloy, 30mm inner width, tubeless ready, DT Swiss 370 Hub, 15x110mm, 28h, Sapim Force Spokes
Inner Tubes
Standard, Presta Valve
Stem
Specialized, 35mm Clamp, 35mm Reach
Handlebars
Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep
Grips
Deity Supracush, Lock On, 34mm OD, 133mm Length
Saddle
Bridge Comp, Hollow Cr-mo rails
Seatpost
Xfusion Manic, infinite adjustable, two bolt head, Remote SLR LE lever, 34.9
Weight
16.79 kg
